Board Thickness :

0.031"" (0.79mm)

Contact Finish :

-

Contact Finish Thickness :

-

Contact Material :

Brass

Flange Diameter :

0.050"" (1.27mm)

Insulation :

Non-Insulated

Length - Above Flange :

0.150"" (3.81mm)

Length - Below Flange :

0.051"" (1.30mm)

Length - Overall :

0.221"" (5.61mm)

Mounting Hole Diameter :

0.035"" (0.89mm)

Mounting Type :

Through Hole

Part Status :

Active

Pin Size - Above Flange :

0.025"" (0.64mm) Dia

Pin Size - Below Flange :

0.031"" (0.79mm) Dia

Terminal Style :

Single End

Terminal Type :

PC Pin

Termination :

Swage
